Bloom

Multi-level bloom post-processing

Quick Start

import { createBloom } from './webgpu-market/bloom/bloom';

const bloom = createBloom(device, { format: 'rgba8unorm' });

// Each frame — apply bloom from input texture to output texture
bloom.render(inputTexture, outputTexture, {
  threshold: 0.8,
  strength: 1.0,
  radius: 0.5,
});

bloom.destroy();

Source

// Multi-level bloom — threshold, downsample (Jimenez 13-tap), Gaussian blur, tent upsample, composite
// Based on the Call of Duty: Advanced Warfare bloom presentation (Jimenez 2014)

struct BloomUniforms {
  threshold: f32,
  soft_knee: f32,
  strength: f32,
  radius: f32,
  texel_size: vec2<f32>,
  direction: vec2<f32>,
}

@group(0) @binding(0) var<uniform> u: BloomUniforms;
@group(1) @binding(0) var src_texture: texture_2d<f32>;
@group(1) @binding(1) var src_sampler: sampler;
@group(1) @binding(2) var blend_texture: texture_2d<f32>;

struct VertexOutput {
  @builtin(position) position: vec4<f32>,
  @location(0) uv: vec2<f32>,
}

@vertex
fn vs_quad(@builtin(vertex_index) vi: u32) -> VertexOutput {
  var pos = array<vec2<f32>, 6>(
    vec2(-1.0, -1.0), vec2( 1.0, -1.0), vec2(-1.0,  1.0),
    vec2(-1.0,  1.0), vec2( 1.0, -1.0), vec2( 1.0,  1.0),
  );
  var uvs = array<vec2<f32>, 6>(
    vec2(0.0, 1.0), vec2(1.0, 1.0), vec2(0.0, 0.0),
    vec2(0.0, 0.0), vec2(1.0, 1.0), vec2(1.0, 0.0),
  );
  var out: VertexOutput;
  out.position = vec4(pos[vi], 0.0, 1.0);
  out.uv = uvs[vi];
  return out;
}

fn luminance(c: vec3<f32>) -> f32 {
  return dot(c, vec3(0.2126, 0.7152, 0.0722));
}

// 1. Extract bright regions with soft-knee threshold
@fragment
fn fs_threshold(in: VertexOutput) -> @location(0) vec4<f32> {
  let color = textureSample(src_texture, src_sampler, in.uv);
  let lum = luminance(color.rgb);
  let knee = u.threshold * u.soft_knee;
  let contribution = smoothstep(u.threshold - knee, u.threshold + knee, lum);
  return vec4(color.rgb * contribution, 1.0);
}

// 2. 13-tap Jimenez downsample (CoD:AW technique) — high quality, anti-flicker
@fragment
fn fs_downsample(in: VertexOutput) -> @location(0) vec4<f32> {
  let t = u.texel_size;
  let uv = in.uv;

  let a = textureSample(src_texture, src_sampler, uv);
  let b = textureSample(src_texture, src_sampler, uv + vec2(-0.5, -0.5) * t);
  let c = textureSample(src_texture, src_sampler, uv + vec2( 0.5, -0.5) * t);
  let d = textureSample(src_texture, src_sampler, uv + vec2(-0.5,  0.5) * t);
  let e = textureSample(src_texture, src_sampler, uv + vec2( 0.5,  0.5) * t);
  let f = textureSample(src_texture, src_sampler, uv + vec2(-1.0, -1.0) * t);
  let g = textureSample(src_texture, src_sampler, uv + vec2( 0.0, -1.0) * t);
  let h = textureSample(src_texture, src_sampler, uv + vec2( 1.0, -1.0) * t);
  let i = textureSample(src_texture, src_sampler, uv + vec2(-1.0,  0.0) * t);
  let j = textureSample(src_texture, src_sampler, uv + vec2( 1.0,  0.0) * t);
  let k = textureSample(src_texture, src_sampler, uv + vec2(-1.0,  1.0) * t);
  let l = textureSample(src_texture, src_sampler, uv + vec2( 0.0,  1.0) * t);
  let m = textureSample(src_texture, src_sampler, uv + vec2( 1.0,  1.0) * t);

  var result = a * 0.125;
  result += (b + c + d + e) * 0.125;
  result += (f + g + i) * (1.0 / 16.0);
  result += (g + h + j) * (1.0 / 16.0);
  result += (i + k + l) * (1.0 / 16.0);
  result += (j + l + m) * (1.0 / 16.0);

  return result;
}

// 3. 9-tap separable Gaussian blur
@fragment
fn fs_blur(in: VertexOutput) -> @location(0) vec4<f32> {
  let dir = u.direction * u.texel_size * u.radius;

  var result = textureSample(src_texture, src_sampler, in.uv) * 0.2270270270;
  result += textureSample(src_texture, src_sampler, in.uv + dir * 1.0) * 0.1945945946;
  result += textureSample(src_texture, src_sampler, in.uv - dir * 1.0) * 0.1945945946;
  result += textureSample(src_texture, src_sampler, in.uv + dir * 2.0) * 0.1216216216;
  result += textureSample(src_texture, src_sampler, in.uv - dir * 2.0) * 0.1216216216;
  result += textureSample(src_texture, src_sampler, in.uv + dir * 3.0) * 0.0540540541;
  result += textureSample(src_texture, src_sampler, in.uv - dir * 3.0) * 0.0540540541;
  result += textureSample(src_texture, src_sampler, in.uv + dir * 4.0) * 0.0162162162;
  result += textureSample(src_texture, src_sampler, in.uv - dir * 4.0) * 0.0162162162;

  return result;
}

// 4. 9-tap tent upsample + additive combine with current level
@fragment
fn fs_upsample(in: VertexOutput) -> @location(0) vec4<f32> {
  let t = u.texel_size;
  let uv = in.uv;

  var bloom = textureSample(src_texture, src_sampler, uv + vec2(-1.0, -1.0) * t) * (1.0 / 16.0);
  bloom += textureSample(src_texture, src_sampler, uv + vec2( 0.0, -1.0) * t) * (2.0 / 16.0);
  bloom += textureSample(src_texture, src_sampler, uv + vec2( 1.0, -1.0) * t) * (1.0 / 16.0);
  bloom += textureSample(src_texture, src_sampler, uv + vec2(-1.0,  0.0) * t) * (2.0 / 16.0);
  bloom += textureSample(src_texture, src_sampler, uv                        ) * (4.0 / 16.0);
  bloom += textureSample(src_texture, src_sampler, uv + vec2( 1.0,  0.0) * t) * (2.0 / 16.0);
  bloom += textureSample(src_texture, src_sampler, uv + vec2(-1.0,  1.0) * t) * (1.0 / 16.0);
  bloom += textureSample(src_texture, src_sampler, uv + vec2( 0.0,  1.0) * t) * (2.0 / 16.0);
  bloom += textureSample(src_texture, src_sampler, uv + vec2( 1.0,  1.0) * t) * (1.0 / 16.0);

  let current = textureSample(blend_texture, src_sampler, uv);
  return current + bloom;
}

// 5. Final composite: original + bloom × strength
@fragment
fn fs_composite(in: VertexOutput) -> @location(0) vec4<f32> {
  let original = textureSample(src_texture, src_sampler, in.uv);
  let bloom = textureSample(blend_texture, src_sampler, in.uv);
  return vec4(original.rgb + bloom.rgb * u.strength, original.a);
}

import shaderCode from './bloom.wgsl?raw';

export interface BloomParams {
  threshold?: number;
  strength?: number;
  radius?: number;
  softKnee?: number;
}

export interface BloomRenderer {
  render(input: GPUTexture, output: GPUTexture, params?: BloomParams): void;
  destroy(): void;
}

const UNIFORM_SIZE = 32; // 8 floats × 4 bytes

export function createBloom(
  device: GPUDevice,
  options?: { format?: GPUTextureFormat; levels?: number }
): BloomRenderer {
  const format = options?.format ?? 'rgba8unorm';
  const levels = options?.levels ?? 5;
  const alignment = device.limits.minUniformBufferOffsetAlignment;
  const slotSize = Math.max(UNIFORM_SIZE, alignment);

  const shaderModule = device.createShaderModule({ label: 'bloom', code: shaderCode });

  const linearSampler = device.createSampler({
    magFilter: 'linear',
    minFilter: 'linear',
    addressModeU: 'clamp-to-edge',
    addressModeV: 'clamp-to-edge'
  });

  const uniformBGL = device.createBindGroupLayout({
    entries: [
      {
        binding: 0,
        visibility: GPUShaderStage.FRAGMENT,
        buffer: { type: 'uniform', hasDynamicOffset: true, minBindingSize: UNIFORM_SIZE }
      }
    ]
  });

  const singleTexBGL = device.createBindGroupLayout({
    entries: [
      { binding: 0, visibility: GPUShaderStage.FRAGMENT, texture: { sampleType: 'float' } },
      { binding: 1, visibility: GPUShaderStage.FRAGMENT, sampler: {} }
    ]
  });

  const dualTexBGL = device.createBindGroupLayout({
    entries: [
      { binding: 0, visibility: GPUShaderStage.FRAGMENT, texture: { sampleType: 'float' } },
      { binding: 1, visibility: GPUShaderStage.FRAGMENT, sampler: {} },
      { binding: 2, visibility: GPUShaderStage.FRAGMENT, texture: { sampleType: 'float' } }
    ]
  });

  const singleTexLayout = device.createPipelineLayout({
    bindGroupLayouts: [uniformBGL, singleTexBGL]
  });
  const dualTexLayout = device.createPipelineLayout({ bindGroupLayouts: [uniformBGL, dualTexBGL] });

  function makePipeline(
    label: string,
    entry: string,
    layout: GPUPipelineLayout
  ): GPURenderPipeline {
    return device.createRenderPipeline({
      label,
      layout,
      vertex: { module: shaderModule, entryPoint: 'vs_quad' },
      fragment: { module: shaderModule, entryPoint: entry, targets: [{ format }] },
      primitive: { topology: 'triangle-list' }
    });
  }

  const thresholdPipeline = makePipeline('bloom threshold', 'fs_threshold', singleTexLayout);
  const downsamplePipeline = makePipeline('bloom downsample', 'fs_downsample', singleTexLayout);
  const blurPipeline = makePipeline('bloom blur', 'fs_blur', singleTexLayout);
  const upsamplePipeline = makePipeline('bloom upsample', 'fs_upsample', dualTexLayout);
  const compositePipeline = makePipeline('bloom composite', 'fs_composite', dualTexLayout);

  const totalPasses = 1 + (levels - 1) + levels * 2 + (levels - 1) + 1;

  const uniformBuffer = device.createBuffer({
    label: 'bloom uniforms',
    size: totalPasses * slotSize,
    usage: GPUBufferUsage.UNIFORM | GPUBufferUsage.COPY_DST
  });

  const uniformBG = device.createBindGroup({
    layout: uniformBGL,
    entries: [{ binding: 0, resource: { buffer: uniformBuffer, size: UNIFORM_SIZE } }]
  });

  let mips: GPUTexture[] = [];
  let blurTemps: GPUTexture[] = [];
  let allocW = 0;
  let allocH = 0;

  let mipViews: GPUTextureView[] = [];
  let blurTempViews: GPUTextureView[] = [];
  let mipSingleBGs: GPUBindGroup[] = [];
  let blurTempSingleBGs: GPUBindGroup[] = [];
  let upsampleDualBGs: GPUBindGroup[] = [];

  let inputSingleBG: GPUBindGroup | null = null;
  let cachedInputTex: GPUTexture | null = null;
  let compositeDualBG: GPUBindGroup | null = null;
  let cachedCompositeTex: GPUTexture | null = null;

  function makeSingleBG(view: GPUTextureView): GPUBindGroup {
    return device.createBindGroup({
      layout: singleTexBGL,
      entries: [
        { binding: 0, resource: view },
        { binding: 1, resource: linearSampler }
      ]
    });
  }

  function makeDualBG(view: GPUTextureView, blendView: GPUTextureView): GPUBindGroup {
    return device.createBindGroup({
      layout: dualTexBGL,
      entries: [
        { binding: 0, resource: view },
        { binding: 1, resource: linearSampler },
        { binding: 2, resource: blendView }
      ]
    });
  }

  function allocate(w: number, h: number) {
    for (const t of mips) t.destroy();
    for (const t of blurTemps) t.destroy();
    mips = [];
    blurTemps = [];
    inputSingleBG = null;
    cachedInputTex = null;
    compositeDualBG = null;
    cachedCompositeTex = null;
    allocW = w;
    allocH = h;

    let mw = Math.max(1, w >> 1);
    let mh = Math.max(1, h >> 1);
    const usage = GPUTextureUsage.RENDER_ATTACHMENT | GPUTextureUsage.TEXTURE_BINDING;

    for (let i = 0; i < levels; i++) {
      mips.push(device.createTexture({ size: [mw, mh], format, usage }));
      blurTemps.push(device.createTexture({ size: [mw, mh], format, usage }));
      mw = Math.max(1, mw >> 1);
      mh = Math.max(1, mh >> 1);
    }

    mipViews = mips.map((t) => t.createView());
    blurTempViews = blurTemps.map((t) => t.createView());
    mipSingleBGs = mipViews.map((v) => makeSingleBG(v));
    blurTempSingleBGs = blurTempViews.map((v) => makeSingleBG(v));

    upsampleDualBGs = [];
    for (let i = levels - 2; i >= 0; i--) {
      upsampleDualBGs.push(makeDualBG(mipViews[i + 1], mipViews[i]));
    }
  }

  function render(input: GPUTexture, output: GPUTexture, params?: BloomParams) {
    const threshold = params?.threshold ?? 0.8;
    const strength = params?.strength ?? 1.0;
    const radius = params?.radius ?? 0.5;
    const softKnee = params?.softKnee ?? 0.5;

    if (input.width !== allocW || input.height !== allocH) {
      allocate(input.width, input.height);
    }

    // Write all uniform slots
    const uniformData = new ArrayBuffer(totalPasses * slotSize);
    const f32 = new Float32Array(uniformData);
    let passIdx = 0;

    function writeSlot(tx: number, ty: number, dx: number, dy: number) {
      const base = (passIdx * slotSize) / 4;
      f32[base] = threshold;
      f32[base + 1] = softKnee;
      f32[base + 2] = strength;
      f32[base + 3] = radius;
      f32[base + 4] = tx;
      f32[base + 5] = ty;
      f32[base + 6] = dx;
      f32[base + 7] = dy;
      passIdx++;
    }

    writeSlot(1 / input.width, 1 / input.height, 0, 0);
    for (let i = 1; i < levels; i++) writeSlot(1 / mips[i - 1].width, 1 / mips[i - 1].height, 0, 0);
    for (let i = 0; i < levels; i++) {
      const tw = 1 / mips[i].width;
      const th = 1 / mips[i].height;
      writeSlot(tw, th, 1, 0);
      writeSlot(tw, th, 0, 1);
    }
    for (let i = levels - 2; i >= 0; i--)
      writeSlot(1 / mips[i + 1].width, 1 / mips[i + 1].height, 0, 0);
    writeSlot(1 / blurTemps[0].width, 1 / blurTemps[0].height, 0, 0);

    device.queue.writeBuffer(uniformBuffer, 0, uniformData);

    // Encode passes
    const encoder = device.createCommandEncoder({ label: 'bloom' });
    passIdx = 0;

    function pass(targetView: GPUTextureView, pipeline: GPURenderPipeline, texBG: GPUBindGroup) {
      const p = encoder.beginRenderPass({
        colorAttachments: [
          {
            view: targetView,
            clearValue: { r: 0, g: 0, b: 0, a: 1 },
            loadOp: 'clear',
            storeOp: 'store'
          }
        ]
      });
      p.setPipeline(pipeline);
      p.setBindGroup(0, uniformBG, [passIdx * slotSize]);
      p.setBindGroup(1, texBG);
      p.draw(6);
      p.end();
      passIdx++;
    }

    if (!inputSingleBG || cachedInputTex !== input) {
      cachedInputTex = input;
      inputSingleBG = makeSingleBG(input.createView());
    }

    pass(mipViews[0], thresholdPipeline, inputSingleBG);
    for (let i = 1; i < levels; i++) pass(mipViews[i], downsamplePipeline, mipSingleBGs[i - 1]);
    for (let i = 0; i < levels; i++) {
      pass(blurTempViews[i], blurPipeline, mipSingleBGs[i]);
      pass(mipViews[i], blurPipeline, blurTempSingleBGs[i]);
    }
    let upIdx = 0;
    for (let i = levels - 2; i >= 0; i--)
      pass(blurTempViews[i], upsamplePipeline, upsampleDualBGs[upIdx++]);

    if (!compositeDualBG || cachedCompositeTex !== input) {
      cachedCompositeTex = input;
      compositeDualBG = makeDualBG(input.createView(), blurTempViews[0]);
    }
    pass(output.createView(), compositePipeline, compositeDualBG);

    device.queue.submit([encoder.finish()]);
  }

  function destroy() {
    for (const t of mips) t.destroy();
    for (const t of blurTemps) t.destroy();
    uniformBuffer.destroy();
  }

  return { render, destroy };
}

Documentation

bloom

Multi-level bloom post-processing. Extracts bright regions, builds a mipmap pyramid with Jimenez 13-tap downsampling, applies separable Gaussian blur at each level, upsamples with tent filtering, and composites the result back onto the original image.

API

`createBloom(device, options?)`

device — GPUDevice
options.format — Texture format. Default 'rgba8unorm'.
options.levels — Number of mip levels in the bloom pyramid. Default 5.

Returns { render, destroy }.

`render(input, output, params?)`

Applies bloom from input texture to output texture. Both must have TEXTURE_BINDING usage; output must also have RENDER_ATTACHMENT.

params.threshold — Brightness threshold for bloom extraction. Default 0.8.
params.strength — Bloom intensity multiplier. Default 1.0.
params.radius — Blur radius scale. Default 0.5.
params.softKnee — Soft threshold transition width. Default 0.5.

Rationale

Bloom simulates the way bright light bleeds into surrounding areas in cameras and the human eye. It's one of the most common post-processing effects in games and real-time graphics — any scene with HDR lighting, emissive materials, or bright light sources benefits from bloom. Without it, bright areas look flat and clipped.

This module implements a production-quality bloom pipeline used in shipped AAA games, in a single self-contained WebGPU file.

Original Research

Jorge Jimenez (2014) — Next Generation Post Processing in Call of Duty: Advanced Warfare — The presentation that introduced the 13-tap downsample filter used in this module. The key insight is using a weighted combination of 13 bilinear taps instead of a simple box filter, which prevents aliasing and fireflies in the bloom. https://www.iryoku.com/next-generation-post-processing-in-call-of-duty-advanced-warfare/
Kawase (2003) — Frame Buffer Postprocessing Effects in DOUBLE-S.T.E.A.L — An earlier approach using iterative dual-blur that's cheaper but lower quality. Good context for understanding the design space.

Existing Implementations

Unity HDRP Bloom — Unity's built-in bloom uses the same Jimenez downsample approach.
three.js UnrealBloomPass — Three.js implementation of multi-level bloom, good for cross-referencing. https://github.com/mrdoob/three.js/blob/dev/examples/jsm/postprocessing/UnrealBloomPass.js

Further Learning

LearnOpenGL: Bloom — Step-by-step tutorial explaining the bloom pipeline with diagrams. https://learnopengl.com/Advanced-Lighting/Bloom
Alexander Christensen: HDR Bloom — Practical guide to implementing bloom in a modern rendering pipeline, covers threshold, downsampling, and compositing.
